PVC SLIDING SYSTEM
Large glazings enliven the rooms. The door construction is designed to provide optimum stability, allow the use of large glazing sizes and offer a choice of several operation patterns.
EvolutionDrive is distinguished by the greatest possible flexibility. The clever design combined with the modern style of the construction helps to create a cosy atmosphere in the room and adapts to any individual architectural style. The available colour options bring your interior to life.
The sealing system – especially in the middle section – guarantees effective thermal insulation. In addition to high functionality, Lift&Slide doors are distinguished by an innovative (patent pending) solution for burglar resistance up to resistance class RC 2. The security mechanism works independently of the hardware used and at the same time enables the use of flat rail thresholds or renovation thresholds. In this way, it meets all the requirements for barrier-free housing while at the same time providing burglary protection.
Features of evolutionDrive HST
evolutionDrive HST color anthracite
Thermics
Uw= 1,30 W/m²*K
(for Ug= 1,1 W/m²*K)
Acustics
32 dB
Water resistance
Uncovered 2A
Warranty
2 years warranty on fittings as standard, 5 years on profile
Variants
| Thermics: | Uw= 1,30 W/m²*K (for Ug= 1,1 W/m²*K) |
| Number of chambers | 6 |
| Watertightness | 2A (uncovered) |
| Resistance to wind load | C2 |
| Air exchange | 3 |
| Load-bearing capacity of safety devices | 350N |
| Solar radiation coefficient (g) | 63 |
| Light transmittance | 80 |
What we offer in standard?
3-point locking system
Leaves up to 400 kg
Possibility to embed in the threshold to 48 mm
Leaf sizes over 3x3m
What else can we offer?
Leaf weight up to 600kg
Opening support
SilentClose
